BOTE IMAGING LENS
Bote has been established for 22 years and focuses on the production of various imaging lenses. We guarantee to achieve the various technical indicators and delivery times promised to you.
Fisheye Imaging Lenses
Specification:
- 2/3″, C-Mount Lens
- Wide Field of View (185°) for Fisheye Images
- Lockable Iris Control and Fixed Focus
- 1.8mm Focal Length
- TTL:14.51mm, customizable
- Can match the sensor with 1/2.7″ image surface, customizable
- Various IRs can be installed, such as: IR650nm, IR850nm, IR940nm, IR650-850nm/DN
- Various fisheye lenses for option.
Feature of the Lens:
Fisheye Imaging Lenses are designed to support MegaPixel resolution cameras across a 185° field of view. Their large depth of field eliminates the need for focus adjustment and allows the lenses to be sharply focused between 100mm and infinity.
A lockable iris adjustment enables control over the exposure without changing integration time and stays locked in place to prevent accidental alteration.
Fisheye Imaging Lenses are excellent for space-constrained applications where large fields of view are required at short working distances. These lenses have a 1.8mm focal length. *FOV for ½” format sensor.
Application of the Lens:
Vehicle-mounted, security monitoring, smart home, Smart vending machine lens
Introduction of the Lens:
In general, there is no clear definition of fisheye lens. The improved lens will protrude forward like the eyes of a fish, so it is called fisheye lens.
From the perspective of lens parameters, a lens with an angle exceeding 90 degrees can be called a wide-angle lens.
A lens with an angle close to 180 degrees or greater can be called a fisheye lens or ultra-wide-angle lens.
Bote’s fisheye lens series selection provides users with more comprehensive understanding of large-scale shooting scenery.
